KLEA240F
Key Product Features
- Basic Function DIN Rail Power Supply
- Ultra Slim Dimensions
- Cost Effective
- DC OK Function
- 5 Year Warranty
- EN & UL Approved
Options
KL□(1) A(2) 240(3) F(4) - □□(5) - □(6)
(1) Series nameKHE: Euro style I/O terminals
KHN: Barrier blocks style I/O terminals
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage
(6) Option
C: with Coating
N2: Screw mounting
3D product images are available.
Read Me First
Standard model
| Basic Specification | KLEA240F-24 | KLEA240F-48 |
|---|---|---|
| Check Stock | Check Stock | |
| Input Voltage Range | AC85 - 264V 1Φ | |
| Output Voltage / Current | 24V 10A | 48V 5A |
| Output Power | 240W | |
| Output Voltage Adj Range | 21.60 - 26.40V | 43.20 - 52.80V |
| Operating Temp (°C) | -20 to +70℃, 20 - 90%RH（Non condensing）, Type tested for -40℃ start-up（Required to Derating） | |
| Cooling Method | Convection | |
| Dimensions (W x H x D) | 50x124x117mm | |
| Safety Agency Approvals | UL60950-1, C-UL (CSA60950-1) , EN62368-1, UL508, Complies with DEN-AN |
|
| Technical Data | KLEA240F-24 | KLEA240F-48 |
| Performance Data | ||
| EMC Data | ||
| Expected Life | ||
| MTBF | ||
| Reliability Data | ||
